SunGuard® Double Silver

Neutral 50

Add to Compare

Download Brochure Generate specification Find a Supplier

Product information

Substrates

Clear 4-12 mm

Applications

Windows
Skylights
Facades
Spandrel

Manufacturing Options

Heat Strengthened
Heat Soaked
Standard PVB
Laminated
Tempered

Recommended Coating Positions

Surface 2 (double IGU)

Maximum Size

<3660x2550mm

Edge Deletion

Glass Type

Low E

Glass Functions

Solar control
Thermal insulation

Fabrication Options

Must be used in an Insulating Glass Unit

Appearance

Neutral

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Double Glazed

Double Glazed

GLASS: Clear Float (Middle East) Glass, 1/4" (6mm) (2-SunGuard® DS 40 T (Middle East) )

GAP: 100% Air 12.0mm

GLASS: Clear Float (Middle East) Glass, 3/16" (5mm)

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

39 %

Reflectance outside (ρv)

11 %

Reflectance inside (ρv)

17 %

General Color Rendering Index (CRI)

83.4

Ultraviolet

Transmittance UV (τuv)

22 %

Solar Energy

Solar transmittance (τe)

18 %

Reflectance outside (ρe)

28 %

Reflectance inside (ρe)

33 %

Solar absorptance (αe)

54 %

Solar Heat Gain Coefficient (SHGC)

0.24

Shading Coefficient (sc)

0.27

Thermal properties

Winter night U-Value

1.677 W/m²·K

Summer day U-value

1.629 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.62
