SunGuard® Solar Plus

Neutral 45

Add to Compare

Download Brochure Calculate Performance Generate BIM Files Generate specification Find a Supplier

Download Brochure Generate BIM Files Generate specification Find a Supplier

The latest development in the Guardian SunGuard® Solar Plus range of coated solar control glass, SunGuard® Solar Plus Neutral 45 offers a highly desirable, neutral, transparent appearance, resulting in true views on the

outside. The glass minimizes the need for artificial lighting, while still providing superior solar control and thermal insulation, making it ideal for premium residential and commercial builds.

Solar Plus Neutral 45 combines several compelling benefits: good solar control, high natural light transmission (44%), yet also low solar heat gain (SHGC of 0.35), allowing the glass to meet the new Indian green building codes.

Solar Plus Neutral 45 provides low internal and external light reflection (6% and 16% respectively), adding a much more neutral tone to the glass when viewing the glass from inside and outside. If a building is in use around the clock, the glass allows occupants to enjoy better views of the outside world.

Solar Plus Neutral 45 can be used in a wide range of commercial and residential applications including curtain walls, facades, windows, spandrels, roof windows and skylights. The glass can be used in a double insulating glass unit or in monolithic applications, where the glass has been tested and proven for its durability.

Solar Plus Neutral 45 is designed on clear float glass. The glass is available annealed or in a heat treatable version for safety, security or acoustic applications.

Product information

Substrates

Clear 4-12 mm

Applications

Windows
Skylights
Facades
Spandrel
Roof window
Curtain walls

Manufacturing Options

Heat Strengthened
Crystal clear PVB
Annealed
Silk screen frit
Standard PVB
Bent
Laminated
Tempered

Recommended Coating Positions

Surface 2 (double IGU)
Surface 2 (single IGU)

Maximum Size

<3660x2550mm

Edge Deletion

Glass Type

Durable Coated Glass

Glass Functions

Reflective
Aesthetics
Solar control

Fabrication Options

Can be Laminated
Can be used Monolithic
Can be in an Insulating Glass Unit

Appearance

Neutral

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option

Substrate

There is only one substrate available for this product

View

Left sky conditions

Right sky conditions

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Launch Glass Visualizer

Calculate Performance Values & Generate BIM Files

Generate product performance data for custom glass make-ups and create detailed BIM object files for your project

Calculate

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Monolithic
Double Glazed

Monolithic

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm) (2-SunGuard® Solar Plus Neutral 45 (India))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

44 %

Reflectance outside (ρv)

16 %

Reflectance inside (ρv)

6 %

General Color Rendering Index (CRI)

90.1

Ultraviolet

Transmittance UV (τuv)

24 %

Solar Energy

Solar transmittance (τe)

24 %

Reflectance outside (ρe)

22 %

Reflectance inside (ρe)

30 %

Solar absorptance (αe)

53 %

Solar Heat Gain Coefficient (SHGC)

0.35

Shading Coefficient (sc)

0.41

Thermal properties

Winter night U-Value

3.997 W/m²·K

Summer day U-value

3.225 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.24

Embodied Co2

[eq. kg/m²] A1-A3

21.18

Double Glazed

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm) (2-SunGuard® Solar Plus Neutral 45 (India))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm)

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

39 %

Reflectance outside (ρv)

17 %

Reflectance inside (ρv)

13 %

General Color Rendering Index (CRI)

88.2

Ultraviolet

Transmittance UV (τuv)

18 %

Solar Energy

Solar transmittance (τe)

20 %

Reflectance outside (ρe)

23 %

Reflectance inside (ρe)

24 %

Solar absorptance (αe)

57 %

Solar Heat Gain Coefficient (SHGC)

0.29

Shading Coefficient (sc)

0.33

Thermal properties

Winter night U-Value

2.053 W/m²·K

Summer day U-value

2.117 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.35

Embodied Co2

[eq. kg/m²] A1-A3

38.80

Performance Calculations

SunGuard® Solar Plus

Neutral 45

Monolithic Not Laminated Monolithic Laminated Double Glazed Not Laminated Double Outer pane Laminated Double Inner pane Laminated Double Inner and Outer pane Laminated Triple Glazed Not Laminated Triple Outer pane Laminated Triple Inner pane Laminated Triple Inner and Outer pane Laminated

With the performance calculator, you can quickly calculate the performance data that matches your own glazing make-up

1 Pane
2 calculation format
3 Results

1 Outer Pane
2 Inner Pane
3 cavity
4 calculation format
5 Results

1 Outer Pane
2 Middle Pane
3 Inner Pane
4 cavity
5 calculation format
6 Results

Choose a glazing

Monolithic

Not available for this product
Double

Not available for this product
Triple

Not available for this product

Monolithic

Monolithic Laminated

Double Glazed

Double Outer pane Laminated

Double Inner pane Laminated

Double Inner and Outer pane Laminated

Triple Glazed

Triple Outer pane Laminated

Triple Inner pane Laminated

Triple Inner and Outer pane Laminated

Outer Pane

Base glass *

There is only one substrate available for this product.

PVB interlayer thickness *

There is only one Interlayer available for this product.

Backing glass *

There is only one substrate available for this product.

Base glass thickness *

There is only one thickness available, to calculate other thickness' please go to Glass Analytics

Glass thickness are symetrical and represent the glass to be laminated

Coating on surface 1 *

There is only one coating available

Coating on surface 2 *

There is only one coating available

Coating on surface 3 *

There is only one coating available

Coating on surface 4 *

There is only one coating available

Middle Pane

Base glass *

There is only one substrate available for this product.

Base glass thickness *

There is only one thickness available, to calculate other thickness' please go to Glass Analytics

Coating on surface 3 * Coating on surface 5 *

There is only one coating available

Coating on surface 4 * Coating on surface 6 *

There is only one coating available

Inner Pane

Base glass *

There is only one substrate available for this product.

PVB interlayer thickness *

There is only one Interlayer available for this product.

Backing glass *

There is only one substrate available for this product.

Base glass thickness *

There is only one thickness available, to calculate other thickness' please go to Glass Analytics

Glass thickness are symetrical and represent the glass to be laminated

Coating on surface 5 * Coating on surface 3 * Coating on surface 7 *

There is only one coating available

Coating on surface 6 * Coating on surface 4 * Coating on surface 8 *

There is only one coating available

Coating on surface 7 * Coating on surface 5 * Coating on surface 9 *

There is only one coating available

Coating on surface 8 * Coating on surface 6 * Coating on surface 10 *

There is only one coating available

Choose your calculation format

Standardization *

There is only one calculation standard available

Unit Display *

There is only one unit available for this calculation standard

Results

Calculated Values are in accordance with

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Generate specifications

Generate BIM Objects

Launch another simulation

Need further technical support? Get in contact

There is something wrong with your selection

Performance Data is not currently available for this glass make-up, please launch a new simulation or go to Glass Analytics to configure performance data for your required glass make-up.

Launch another simulation

Submission failed due to a error, please try again

This tool is unavailable on this device

Access our website on a bigger device to be able to use our comparison tool.

Neutral 45

Monolithic

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm) (2-SunGuard® Solar Plus Neutral 45 (India))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

44 %

Reflectance outside (ρv)

16 %

Reflectance inside (ρv)

6 %

General Color Rendering Index (CRI)

90.1

Ultraviolet

Transmittance UV (τuv)

24 %

Solar Energy

Solar transmittance (τe)

24 %

Reflectance outside (ρe)

22 %

Reflectance inside (ρe)

30 %

Solar absorptance (αe)

53 %

Solar Heat Gain Coefficient (SHGC)

0.35

Shading Coefficient (sc)

0.41

Thermal properties

Winter night U-Value

3.997 W/m²·K

Summer day U-value

3.225 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.24

Embodied Co2

[eq. kg/m²] A1-A3

21.18

Neutral 45

Double Glazed

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm) (2-SunGuard® Solar Plus Neutral 45 (India))

GAP: 100% Air 12.0mm

GLASS: Guardian Clear Glass (India) Glass, 1/4" (6mm)

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

39 %

Reflectance outside (ρv)

17 %

Reflectance inside (ρv)

13 %

General Color Rendering Index (CRI)

88.2

Ultraviolet

Transmittance UV (τuv)

18 %

Solar Energy

Solar transmittance (τe)

20 %

Reflectance outside (ρe)

23 %

Reflectance inside (ρe)

24 %

Solar absorptance (αe)

57 %

Solar Heat Gain Coefficient (SHGC)

0.29

Shading Coefficient (sc)

0.33

Thermal properties

Winter night U-Value

2.053 W/m²·K

Summer day U-value

2.117 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

1.35

Embodied Co2

[eq. kg/m²] A1-A3

38.80

Can’t find the glass make-up you are looking for? Go to Glass Analytics for more detailed configurations:

Launch Glass Analytics
