Solar control for creative applications

Produced with the patented Silacoat® process, SunGuard® Solar Neutral 67 offers a combination of practical benefits and enhanced product features, including enhanced chemical and mechanical durability, when compared to traditional sputter coated products.

Product information

Substrates

Gray 3-12mm
Green 3-12mm
Clear Float 3-12 mm

Applications

Windows
Skylights
Facades
Roof window
Curtain walls
Doors

Manufacturing Options

Heat Strengthened
Heat Soaked
Annealed
Tempered
Laminated

Recommended Coating Positions

Surface 2 (double IGU)

Maximum Size

<3210x6000mm

Edge Deletion

Glass Type

Durable Coated Glass

Glass Functions

Solar control

Fabrication Options

Can be used Monolithic
Can be in an Insulating Glass Unit

Appearance

Neutral

Visual Appearance

Use the Glass Visualizer to get an introductory understanding of how glass will appear in use. Use the Glass Analytics tools to explore even more options for color and performance.

Choose an option

Substrate

There is only one substrate available for this product

View

Left sky conditions

Right sky conditions

This tool intended to represent the reflected/transmitted color ; however, glass color cannot be accurately portrayed online. For more information, launch the Glass Visualizer.

You need more information and additional mockups? Consult our Glass Visualizer Tool:

Launch Glass Visualizer

Calculate Performance Values & Generate BIM Files

Generate product performance data for custom glass make-ups and create detailed BIM object files for your project

Calculate

Performance data

The glazing make-up suggestions below are pre-defined to provide examples of commonly used combinations of products. There are many other glass combinations available at Glass Analytics.

Default Performance Data
Performance Calculations

Monolithic
Double Glazed

Monolithic

GLASS: Clear Float (Middle East & Africa) Glass, 3/16" (5mm) (2-SunGuard® Solar Neutral 67 (Middle East - Discontinued))

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

66 %

Reflectance outside (ρv)

16 %

Reflectance inside (ρv)

18 %

General Color Rendering Index (CRI)

99.3

Ultraviolet

Transmittance UV (τuv)

48 %

Solar Energy

Solar transmittance (τe)

63 %

Reflectance outside (ρe)

12 %

Reflectance inside (ρe)

15 %

Solar absorptance (αe)

25 %

Solar Heat Gain Coefficient (SHGC)

0.70

Shading Coefficient (sc)

0.82

Thermal properties

Winter night U-Value

5.810 W/m²·K

Summer day U-value

5.256 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

0.94

Embodied Co2

[eq. kg/m²] A1-A3

18.39

Double Glazed

GLASS: Clear Float (Middle East & Africa) Glass, 3/16" (5mm) (2-SunGuard® Solar Neutral 67 (Middle East - Discontinued))

GAP: 10% Air, 90% Argon 12.0mm

GLASS: Clear Float (Middle East & Africa) Glass, 3/16" (5mm)

Calculated Values are in accordance with NFRC2010

Performance Values For more details on the performance values displayed and Embodied CO2 please click here

Visible Light

Transmittance (τv)

60 %

Reflectance outside (ρv)

20 %

Reflectance inside (ρv)

23 %

General Color Rendering Index (CRI)

98.1

Ultraviolet

Transmittance UV (τuv)

38 %

Solar Energy

Solar transmittance (τe)

53 %

Reflectance outside (ρe)

15 %

Reflectance inside (ρe)

18 %

Solar absorptance (αe)

32 %

Solar Heat Gain Coefficient (SHGC)

0.61

Shading Coefficient (sc)

0.70

Thermal properties

Winter night U-Value

2.546 W/m²·K

Summer day U-value

2.720 W/m²·K

Light to Solar Gain

Light to Solar Gain (LSG)

0.99

Embodied Co2

[eq. kg/m²] A1-A3

33.23
